Manufacturing aviation industry - milling

Equipment

Machinery & system environment

We are well equipped. The working environment at PAYR always keeps up with the latest hard and software. Modern technology, cutting-edge machinery, state-of-the-art programs and special applications are the basis for process optimization and high-end outcomes.

These are the materials processed at PAYR:

  • Stainless steel
  • Steel
  • Aluminum
  • Titanium and alloys
  • Synthetics like PMMA, PP, PCTFE, Peek

Machines

Status

June 2021

Milling
Definition

Machine typeTraverse paths
  • HAAS VF11
3048 × 1016 × 762
  • HAAS VF3-SS
1016 × 660 × 365
  • HAAS VF1
508 × 508 × 508
  • MTCUT V 110T
1100 × 610 × 610
  • MTCUT V 232 F
2320 × 710 × 610
  • AVIA FNE 40P
620 × 420 × 400
  • MTCUTV130 TH-Y
    with 5 axle assembly
1300x715x700
  • MTCUT V220 PS
2300x1800x800

Welding

  • WIG welder
  • MAG welder Fronius Transarc 500
  • Hot air plastic welder

Bonding /Welding of synthetic material

We are experienced in the field of PMMA bonding and plastic welding of PP, PFA and PVDF.

3D-printing

  • Formiga P110
Print range 230x275x340
  • EOS P395
Print range 355x355x600

Turning
Definition

Machine typeTraverse paths
  • Weiler NC Drehbank E80,
800 × 2000 × 106
  • Weiler NC Drehbank E70,
700 × 2000 × 106
  • Haas CNC Drehm.,
800 × 450 × 55
  • Spinner TC 400

  • Spinner TC 600


Cutting to size

  • NC-controlled cutting /double miter band saw
  • Milwankee miter saw

Quality assurance & Description

  • Mitutoyo B 231 measuring machine
  • TESA HITE PLUS D 600 digital height measuring instrument
  • Optronis CAMRECORD 450 high speed camera GORATEC TVS 200EX thermal imaging camera

Balancing machine

  • Schenk H4U
balancing diameter Ø1.500mm

System environment

CAD programs

  • CATIA V5/V6
  • INVENTOR
  • SolidWorks / Solid Edge
  • AutoCAD
  • WSCAD
  • UG NX
  • Creo

Calculation systems

  • Abaqus
  • Sigmas

Control systems

  • Simatic S7
  • Codesys
  • Beckhoff
  • Labview
